we supply chromed bar and tubes for hydualic and pheumatic cylinders, pto shaft, agricultural gearboxes etc.
Overview
Quick Details
- Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, farms, Construction works , Energy & Mining, agricultural machiner
Main products include: manure spreading truck, potato planting/harvesting machine, disc plough, disc harrow, grass Mower/slasher, corn and wheat thershers, seeder, mouldboard plow, deep subsoiler machines, rotary tiller, rear blade, fertilizer spreader, combine rice harvester, corn thresher, farm trailer, ridger, trencher, stubble cleaner, earth auger, cultivator and its accessories: Plow disc blades, harrowing film, plough tip and share, cultivator tine, casting parts etc.
- Product name:
-
ANSI 60 Roller Chain Sprocket With Pitch 19.05mm
- Precision:
-
High precision
- Application:
-
Transmission machine
- Surface treatment:
-
Black oxide, Zinc plated
- Bore:
-
Finished bore, Precossing bore,Taper bore
- Processing:
-
Hobbing
- Heat treatment:
-
High Frenquency Quenching
- Color:
-
Nature steel or black
- Groove:
-
Simplex, Duplex, Triplex
- Usage:
-
Transmission Spare Parts
Are you searching for a PTO water pump or PTO- driven generator? Hundreds of PTO parts from EPG mean you can find PTO shaft parts and accessories for whatever kind of equipment you’re working with. From PTO drive shafts to shield parts, we have dozens of replacement PTO parts. We stock Eurocardan parts as well as Neapco parts because those are names you can trust. Whether you need flex couplers or PTO shaft assemblies, we can help.
Supply Ability
- Supply Ability:
- 10000 Piece/Pieces per Week
Packaging & Delivery
A worm gearbox consists of a cylinder with a spiral groove mounted on a shaft. A gear meshes with the spiral groove on the cylinder, and when the cylinder rotates, it causes the gear to rotate also.
- Packaging Details
- Carton ,Wooden case or as your need
- Port
- Tianjin/Shanghai/Qingdao
Online Customization
Product Description
|
ANSI 60 Roller Chain Sprocket With Pitch 19.05mm |
|
|
Bore |
Finished bore, Precossing bore, Taper bore |
|
Color |
Nature steel or black |
|
Standard |
ANSI, DIN, ISO |
|
Type |
Simplex, Duplex, Triplex |
|
Surface treatment |
Black oxide, Zinc plated |
|
Heat treatment |
High Frenquency Quenching |
|
Match 60# Roller Chain Size |
|||
|
ANSI Chain No. |
60 |
||
|
DIN/ISO Chain No. |
12A-1 |
||
|
Pitch |
19.050mm |
||
|
Roller diameter |
11.91mm |
||
|
Width between inner plates |
12.57mm |
||
|
Pin diameter |
5.94mm |
||
|
Plate thickness |
2.42mm |
||
Product Show
Specification
|
Short Pitch Precision Roller Chain (A series)-Simplex Roller Chain & Bushing Chains |
||
|
DIN/ISO Chain No. |
ANSI Chain No. |
Pitch(mm) |
|
*04C-1 |
*25 |
6.350 |
|
*06C-1 |
*35 |
9.525 |
|
085-1 |
41 |
12.700 |
|
08A-1 |
40 |
12.700 |
|
10A-1 |
50 |
15.875 |
|
12A-1 |
60 |
19.050 |
|
16A-1 |
80 |
25.400 |
|
20A-1 |
100 |
31.750 |
|
24A-1 |
120 |
38.100 |
|
28A-1 |
140 |
44.450 |
|
32A-1 |
160 |
50.800 |
|
36A-1 |
180 |
57.150 |
|
40A-1 |
200 |
63.500 |
|
48A-1 |
240 |
76.200 |
|
Short Pitch Precision Roller Chain (A series)-Duplex Roller Chain & Bushing Chains |
||
|
DIN/ISO Chain No. |
ANSI Chain No. |
Pitch(mm) |
|
*04C-2 |
*25-2 |
6.350 |
|
*06C-2 |
*35-2 |
9.525 |
|
085-2 |
41-2 |
12.700 |
|
08A-2 |
40-2 |
12.700 |
|
10A-2 |
50-2 |
15.875 |
|
12A-2 |
60-2 |
19.050 |
|
16A-2 |
80-2 |
25.400 |
|
20A-2 |
100-2 |
31.750 |
|
24A-2 |
120-2 |
38.100 |
|
28A-2 |
140-2 |
44.450 |
|
32A-2 |
160-2 |
50.800 |
|
36A-2 |
180-2 |
57.150 |
|
40A-2 |
200-2 |
63.500 |
|
48A-2 |
240-2 |
76.200 |
|
Short Pitch Precision Roller Chain (A series)-Triplex Roller Chain & Bushing Chains |
||
|
DIN/ISO Chain No. |
ANSI Chain No. |
Pitch(mm) |
|
*04C-3 |
*25-3 |
6.350 |
|
*06C-3 |
*35-3 |
9.525 |
|
08A-3 |
40-3 |
12.700 |
|
10A-3 |
50-3 |
15.875 |
|
12A-3 |
60-3 |
19.050 |
|
16A-3 |
80-3 |
25.400 |
|
20A-3 |
100-3 |
31.750 |
|
24A-3 |
120-3 |
38.100 |
|
28A-3 |
140-3 |
44.450 |
|
32A-3 |
160-3 |
50.800 |
|
36A-3 |
180-3 |
57.150 |
|
40A-3 |
200-3 |
63.500 |
|
48A-3 |
240-3 |
76.200 |
Contact Us
Process
Our Other Products
Spur gear
Helical gear
Gear rack
Bevel gear
Sprocket
Timing pulley
Roller chain
Worm gear & shaft
Linear rail & block
Packing
Usuallu used the suitable for transport by sea, rail, air, and other suitable for import and export customs clearance of free fumigation wooden box of free fumigation wooden pallets (precision products used the collision coating layer in the packaging box, to ensure the goods safe enough).
Remarks:
All items are checked and tested thoroughly during every working procedure, and after the product is finally manufactured to ensure that the best quality product enter into the market.
